- A standard mic stand adapter with allen key (shockmount adapter sold separately).
- Individual measurement data for each microphone.
- Delivered in a Scandinavian birch plywood case (HPRC case with custom foam insert sold separately).
Directional characteristics: Figure-of-Eight
Ribbon dimensions: 60 × 4,7 mm
Ribbon technology: NCRT (Nano Composite Ribbon Technology)
Ribbon profile: Sandhill VariGeo (Variable Geometry)
Principle of operation: Pressure Gradient
Body type: Machined Aluminium
Frequency range: 20 Hz - 15 kHz
Sensitivity (open circuit): 3,5 mV/Pa *
Equivalent noise level (A-weighted): 22 dB ( IEC 651) *
Equivalent noise level (CCIR-weighted): 36 dB (ITU-R BS.468-4) *
S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL) A-weighted: 72 dB*
Max. SPL, peak before clipping: 154dB
Output impedance: 105 ohm, impedance balanced
Current consumption: 3,1mA, 48 volt phantom powered
Connector: 3-pin male XLR connector, pin 2 Hot
Weight: 450 g
Dimensions: 50/172/25 mm
* exact value is available in the microphone's individual measuring data
